Selec HMI – 7″ Touch Screen
Selec HMI – 7″ Touch Screen
Regular price
Rs. 12,499.00
Regular price
Sale price
Rs. 12,499.00
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
| Manufacturer | Selec |
| Model No. | SP112-GT70-S-CE, SP112-GT70-ET-CE |
| Display Specifications | |
| Type | 7” TFT Touch Screen (65536 colours) |
| Resolution | 800×480 pixels |
| Display Size | 7″ Diagonal |
| Backlight | LED |
| Brightness | 300cd/ m2 |
| Span Life | 30000 hrs |
| LCD type | 4 wire high precision resistance network |
| Functional Specifications | |
| Programming method | Windows based software for HMI configuration |
| Processor | A8 600MHz |
| Memory | 256M Flash+256M DRAM |
| USB Host | USB2.0 x 1, Support USB flash disk to update firmware, configure and store data |
| USB Slave | Type B, program download/upload only |
| Ethernet | RJ45 10M/100M self-adaption. Communicates with PLC & PC, Multiple HMI Online. Default IP is 192.168.1.100 |
| Serial Interface | COM1:RS485/422 COM2:RS232 COM3:RS485 |
| DB9 | Male (COM1 and COM2) |
| Mechanical Specifications | |
| Dimensions (W x H x D) mm | 200 x 146 x 32 mm |
| Panel cutout (W x H) mm | 192 x 138 mm |
| Electrical specifications | |
| Power supply voltage | 24V DC (20.4~28.8V DC), 0.3A |
| Rated Power | 7W |
| Permissible power loss | 10 mSec |
| Insulation resistance | Over 50 mΩ @ 500V DC |
| Withstand Voltage Performance | 500V AC 1 min |
